Sponsors: Fondmetal, Spal, Scaini, Mara TRANSMISSION Gearbox: Osella/Hewland six-speed Driveshafts: Löbro/Osella Clutch: AP CHASSIS Front suspension: double wishbone, pullrod Rear suspension: double wishbone, pullrod Suspension dampers: Koni Wheel diameter: front: 13 in, rear: 13 in. Wheel rim widths: front: 11.5 in, rear: 16.5 in. Tyres: Pirelli Brakes: Brembo Brake pads: Carbone Industrie Steering: Osella Radiator: Secan Fuel tanks: ATL Battery: Magneti Marelli Instruments: Digitech DIMENSIONS Wheelbase: 112.2 in./2850 mm Track: front: 70.8 in./1800 mm rear: 66.1 in./1680 mm Formula weight: 1102.3 lb/500 kg Fuel capacity: 43.9 gallons/200 litres ENGINE Type: Cosworth DFR No. of cylinders: V8 (90°) Bore and stroke: 90 mm x 68.65 mm Capacity: 3494 cc Compression ratio: 12.5:1 Maximum power: 595 bhp @ 10,750 rpm Maximum rpm: 11,000 Valve sizes: 1.46 in. inlet, 1.25 in. exhaust Valve lift: 0.46 in. inlet. 0.41 in. exhaust Valve timing: 102°/102° Block material: aluminium alloy Pistons and rings: Cosworth Bearings: Vandervell Fuel injection: Cosworth/Bosch Injectors Ignition system: Lucas CD Fuel and oil: Agip Sparking plugs: Champion Weight: 315 lb/142.8 kg
Races
16
Race Starts
9
Drivers' Titles
0
Constructors' Titles
0
Victories
0
Poles
0
Fastest Laps
0
Podiums
0
Points
0
Laps
216
One/two finishes
0
StatisticsGPs040506Specifications
