Sponsors: Saudia Arabian Airlines, Albilad TRANSMISSION Gearbox: Hewland FGA400 six-speed Driveshafts: Williams Clutch: Borg & Beck CHASSIS Front suspension: Top rocker arms, bottom wishbones, inboard springs Rear suspension: Lower wishbones and links, single top links, single radius rods, outboard springs Suspension dampers: Koni Wheel diameter: front: 13 in. rear: 13 in Wheel rim widths: front: 11 in. rear: 18 in. Tyres: Goodyear Brakes: Girling front, Lockheed rear Brake pads: Ferodo Steering: Williams rack and pinion Radiators: Volkswagen Fuel tank: Marston Battery: Yuasa Instruments: Veglia DIMENSIONS Wheelbase: 100 in./2540 mm Track: front: 62 in./1575 mm rear: 60 in./1524 mm Gearbox weight: 102 lb/46 kg Chassis weight (tub): 110 lb/50 kg Formula weight: 1290 lb/585 kg Fuel capacity: 42 gal./191 litres Fuel consumption: 5.5 mpg – 51 litres/100 km ENGINE Type: Ford Cosworth DFV No. of cylinders: V8 Bore and stroke: 85.7 mm x 64.8 mm Capacity: 2993 cc Compression ratio: 12:1 Maximum power: 475 bhp Maximum rpm: 10,750 Valve sizes: 34.50 mm x 2/29 mm x 2 Valve lift: 10.4 mm Valve timing: 62/86, 86/62 Pistons and rings: Cosworth/Hepworth & Grandage Bearings: Vandervell Fuel injection: Lucas Ignition system: Lucas Weight: 365 lb/166 kg Fuel and oil: Texaco Sparking plugs: Champion
Races
16
Drivers' Titles
0
Constructors' Titles
0
Victories
0
Poles
0
Fastest Laps
2
Podiums
1
Points
11
Laps
771
One/two finishes
0
StatisticsGPs001002Specifications
